MULTI-TEC PLC

Exterior Wall-Mount

Air Conditioner

MULTI-TEC-PLC Series

W18LBP-W36LBP

The MULTI-TEC Wall-Mount Air Conditioner utilize PLC technology to allow multiple units to operate connected to a single LC6000 controller. When installed with an optional 100% free cooling economizer, the unit will supply full-rated airflow in free cooling mode with the ability to exhaust unconditioned indoor air without the need for additional relief openings in the structure.

Find a Rep

Cabinet Colors
color swatch
X = Beige
color swatch
1 = White
color swatch
4 = Buckeye Gray
color swatch
5 = Desert Brown
color swatch
8 = Dark Bronze
color swatch
S = Stainless Steel
color swatch
A = Aluminum
Multi-TEC small cabinet

W18LBP-W36LBP

  • Up to 11.3 EER
  • PLC Control Module
  • Copeland scroll compressors
  • R-410A green refrigerant
  • Copper tube / aluminum fin coils
  • Optional Free Cooling Economizer
  • AHRI Certified
  • ETL Listed (US and Canada)

* For full product specifications see Product Resources tab below.

Model Group Ton Capacity Electrical Supply/Return
(HxW) & Spread (in)
Cabinet
Dimensions (in)
(WxDxH)
W18L 1.5
  • 230/208-60-1
  • 8x20
  • 12x20
  • 20.6
37x21.5x80
W24A 2
  • 230/208-60-1
  • 230/208-60-3
  • 460-60-3
  • 240/220-50-1
  • 415/380-50-3
  • 8x20
  • 12x20
  • 20.6
37x21.5x80
W24L 2
  • 230/208-60-1
  • 230/208-60-3
  • 415-50-3
  • 8x20
  • 12x20
  • 20.6
37x21.5x80
W30A 2.5
  • 230/208-60-1
  • 230/208-60-3
  • 460-60-3
  • 240/220-50-1
  • 415-50-3
  • 8x28
  • 14x28
  • 18
42x21.5x80
W30L 2.5
  • 230/208-60-1
  • 230/208-60-3
  • 460-60-3
  • 415/380-50-3
  • 8x28
  • 14x28
  • 18
42x21.5x80
W36A 3
  • 230/208-60-1
  • 230/208-60-3
  • 460-60-3
  • 240/220-50-1
  • 220/200-50-3
  • 415/380-50-3
  • 8x28
  • 14x28
  • 18
42x21.5x80
W36L 3
  • 230/208-60-1
  • 230/208-60-3
  • 460-60-3
  • 415/380-50-3
  • 8x28
  • 14x28
  • 18
42x21.5x80
W42A 3.5
  • 230/208-60-1
  • 230/208-60-3
  • 460-60-3
  • 220/200-50-3
  • 415/380-50-3
  • 10x30
  • 16x30
  • 30
46x26.5x90
W48A 4
  • 230/208-60-1
  • 230/208-60-3
  • 460-60-3
  • 220/200-50-3
  • 415/380-50-3
  • 575-60-3
  • 10x30
  • 16x30
  • 30
46x26.5x90
W60A 5
  • 230/208-60-1
  • 230/208-60-3
  • 460-60-3
  • 220/200-50-3
  • 415/380-50-3
  • 575-60-3
  • 10x30
  • 16x30
  • 30
46x26.5x99
W72A 6
  • 230/208-60-1
  • 230/208-60-3
  • 460-60-3
  • 415/380-50-3
  • 575-60-3
  • 10x30
  • 16x30
  • 30
46x26.5x99

  • W42ACE-W72ACE Electric Reheat Dehumid Option
  • W42ACM- W72ACM Hot Gas Reheat Dehum Option
  • 2" MERV11 or MERV13 Air Filters
  • LC6000 PLC Controller
  • Supply/Return Grille

  • Ventilation Options for Model Group(s)- W18L, W24A, W24L, W30A, W30L, W36A, W36L, W42A, W48A, W60A, W72A :
    • Blank Off Plate (No Ventilations)
    • Economizer
