MEGA-TEC PLC

Exterior Wall-Mount

Air Conditioner

MEGA-TEC-PLC_STD Series

W090AP - W180BP

The MEGA-TEC is designed for applications requiring a large amount of sensible cooling capacity and limited wall space.  Dual refrigeration circuits and a total of three stages with the lowest stage less than 35% of the total capacity provide cooling for an area with a varying heat load.  MEGA-TEC provides an AHRI certified 10+ EER solution that meets D.O.E. requirements and the efficiency ratings of state and national codes.  Industrial grade indoor and outdoor fans provide years of trouble-free service.  An optional economizer provides full-flow outdoor air intake and room exhaust based on outside temperature or enthalpy.

Find a Rep

Cabinet Colors
color swatch
1 = White

W090AP - W180BP

  • Large Cooling Capacity / High Sensible Capacity
  • Copeland UltraTech Scroll Compressors
  • Dual Refrigerant Circuits
  • Optional Factory Economizer
  • Optional Electric Reheat Dehumidification
  • R-410A Refrigerant
  • 230/208-3-60 & 460-3-60, 575-3-60
  • 220/200-3-50, 415/380-3-50
  • PLC Control Board Logic
  • Industrial Indoor/Outdoor Motors
  • 2" MERV8 Air Filter
  • Airflow & Dirty Filter Switches
  • High & Low Pressure Transducers
  • Supply/Return Temperature Sensors
  • Compressor Crank Case Heater
  • Optional Technical Coil Protection
  • AHRI Certified
  • ETL Listed (US and Canada)

* For full product specifications see Product Resources tab below.

Model Group Ton Capacity Electrical Supply/Return
(HxW) & Spread (in)
Cabinet
Dimensions (in)
(WxDxH)
W090 7.5
  • 230/208-60-3
  • 460-60-3
  • 240/220-50-3
  • 575-60-3
  • 415/380-50-3
  • 16x33
  • 22x43
  • 26
48x55x100
W120 10
  • 230/208-60-3
  • 460-60-3
  • 240/220-50-3
  • 400-60-3
  • 575-60-3
  • 415/380-50-3
  • 16x33
  • 22x43
  • 26
48x55x100
W150 12.5
  • 230/208-60-3
  • 460-60-3
  • 240/220/50-3
  • 400-60-3
  • 575-60-3
  • 415/380-50-3
  • 16x33
  • 22x43
  • 26
48x55x100
W180 15
  • 400-60-3
  • 577-60-3
  • 230/208-60-3 | 220/200-50-3
  • 460-60-3 | 400-50-3
  • 16x55
  • 22x55
  • 26
56x78x100

  • 2" MERV11 or MERV13 Air Filters
  • Economizer Free Cooling Option
  • Electric Heat Option
  • Electric Reheat Dehumidification Option
  • Supply & Return Grilles



  • LC6000 Series PLC Controller
    • Controls Up To 14 Units & Three Zones
  • Single Unit Controller PGD or PGDx

  • Ventilation Options for Model Group(s)- W090, W120, W150, W180 :
    • Blank Off Plate (No Ventilations)
    • Economizer
